Our esteemed clients can avail from us an extensive range of Lead Free Brass Pipe Fittings, that are made up of high-grade raw material and are strong and sturdy in nature as well. Our products are widely used for industrial purposes and are available at different length, sizes and dimensions as per our client’s specifications. Pipe fitting is the occupation of installing or repairing piping or tubing systems that convey liquid, gas, and occasionally solid materials. Adapters are used when connecting two pipes of different types. For example, an adapter could be fitted on the end of a plain pipe to allow a threaded connection at the other side of the adapter. Bushing Fittings – Bushings, sometimes called reducer bushings, are used for connecting two pipes of different sizes.
Technical Details |
|
| Material : | CuZn30/As, CuZn33, CuZn35, CuZn36, CuZn37/p, CuZn38As, CuZn40, CuZn42 |
| Threads : | American UN, NPT, NPTF, BSW, BSP, BSPT, etc. |
| Typical Aplication : | LP and natural gas, flammable liquids, instrumentation, refrigeration, power steering, hydraulic and pneumatic systems |
| Working Pressure Range : | Temperature and type of tubing used are important factors. However, the following table is a good guide for proper selection. Temperature 730F with copper tubing |
| Conformance : | Meets specifications and standards of ASA, ASME, SAE and MS (Military standards). |
| Pressure : | Working Pressure up to 2000 PSI with a 4:1 safety factor depending on tube size. |
| Temperature Range : | -65°F to +250°F (-53° C to + 121° C) range at maximum operating pressures |
| Finish : | Natural Brass, Nickel Plated or any special platings as per customer requirement |
